Film functions

A film consists of instructions, when to draw an image, where to put it, when to play sound ... dependend on film-loops. There are check-points, which define at which film-loop they begin. The instructions themself are relative to the check-points. For example - a film-loop takes 100 milliseconds - a check-point is defined to begin at the 80th film-loop, so after 8 seconds - a DRAW-instruction is positioned after this check-point, so it is valid from this check-point until to the next one - a SOUND-instruction is also positioned after this check-point, but has a VALID-subkey defined, which limits its validness additionally Instructions between check-points are executed simultaneously. See also the command: vg4 film -h

• Functions

• vg4->film->play()

  Play film.


• Environment variables

• VG_DUMP_ON_EXIT

  Whether dump film-data on exit, when calling VG_dest(): - 0: no - 1: yes, dump on stdout - 2: yes, dump on stderr

Example

example.c

/* show a film */

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <sys/types.h>
#include <unistd.h>
#include <errno.h>
#include <vgagames4.h>


int main(int argc, char **argv) {
  struct VG_Rect rect;
  VG_BOOL filmskip;

  (void)argc; (void)argv;

  /* initialize and open window and audio */
  if (!VG_init("test")) { exit(1); }
  if (!vg4->window->open(VG_WINDOW_SIZE_LOW, VG_WINDOW_SCALE_BEST)) { VG_dest(); exit(1); }
  if (!vg4->audio->open(VG_AUDIO_FREQ_MEDIUM, VG_FALSE)) { VG_dest(); exit(1); }

  /* add multilanguage files */
  vg4->mlang->fb_locale("en");
  vg4->mlang->add("mlang");

  vg4->window->fill(VG_COLOR_BLUE);

  /* play film in a centered rectangle, allow skipping */
  rect.x = 30; rect.w = 260;
  rect.y = 20; rect.h = 160;
  vg4->film->play("film", &rect, &filmskip, NULL);
  if (filmskip) { printf("Film was skipped\n"); }

  /* destroy and exit */
  VG_dest();
  exit(0);
}

film/film

[FILM RESOLUTION=260x160 FADEOUT=0 FLOOP=50]

CP_START: 0

# red and yellow sunnyboys moving, hitting and vanishing
CP_SUNNYBOY_RED_START: CP_START
CP_SUNNYBOY_YELLOW_START: CP_START + 30
CP_SUNNYBOY_RED_YELLOW_HIT: CP_SUNNYBOY_YELLOW_START + 40
CP_SUNNYBOY_RED_YELLOW_END: CP_SUNNYBOY_RED_YELLOW_HIT + 15

# green sunnyboy moving
CP_SUNNYBOY_GREEN_START: CP_START + 50
CP_SUNNYBOY_GREEN_END: CP_SUNNYBOY_GREEN_START + 60

film/sb-red.story

[STORY DRAWLEVEL=1]

CHECK: CP_SUNNYBOY_RED_START

# red sunnyboy moves to its hit-position (160,80)
DRAW:
  IMAGE: data/sb_red.bmp
  POSX: 160 * $percent / 100
  POSY: 80

# red sunnyboy greets yellow sunnyboy
DRAW:
  VALID: $percent -ge 80
  TEXT: data/hi.txt
  POSX: 160
  POSY: 60

CHECK: CP_SUNNYBOY_RED_YELLOW_HIT

# play hit-sound
SOUND:
  VALID: $percent -eq 1
  FILE: data/hit.wav

# red sunnyboy vanishes
DRAW:
  IMAGE: data/sb_red.bmp
  POSX: 160
  POSY: 80
  BRIGHT: 100 - ($percent * 100 / 100)

CHECK: CP_SUNNYBOY_RED_YELLOW_END

film/data/hi.txt

%{mlang[fgcolor=0xcc0000]: main:HI%}

mlang/en/main/file.mlang

[[HI]]
Hi, Sunnyboy!

film/sb-yellow.story

[STORY DRAWLEVEL=1]

CHECK: CP_SUNNYBOY_YELLOW_START

# yellow sunnyboy moves to its hit-position (180,80)
DRAW:
  IMAGE: data/sb_yellow.bmp
  POSX: 260 - (260 - 180) * $percent / 100
  POSY: 80

CHECK: CP_SUNNYBOY_RED_YELLOW_HIT

# yellow sunnyboy vanishes
DRAW:
  IMAGE: data/sb_yellow.bmp
  POSX: 180
  POSY: 80
  BRIGHT: 100 - ($percent * 100 / 100)

CHECK: CP_SUNNYBOY_RED_YELLOW_END

film/sb-green.story

[STORY DRAWLEVEL=1]

CHECK: CP_SUNNYBOY_GREEN_START

# green sunnyboy moves from top to botton
DRAW:
  IMAGE: data/sb_green.bmp
  POSX: 100
  POSY: (160 + 32) * $percent / 100

CHECK: CP_SUNNYBOY_GREEN_END

film/music.story

[STORY]

CHECK: CP_START

# play background-music
MUSIC:
  FILE: data/music.wav
  PLAY: END

# as music-playing will not end at end of its story, the end-checkpoint can be equal to the start-checkpoint
CHECK: CP_START
